Two-Wing Revolving Door
Classic two-wing revolving door, suitable for main entrances of star-rated hotels and Grade A office buildings, combining energy-saving insulation with a prestigious image display.
Technical Specifications
| Door Type | Two-Wing Center Rotation |
| Clear Passage Width | 1800mm |
| Rotation Diameter | 2400-3600mm |
| Drive Method | Variable Frequency Motor + PLC Control |
| Protection Level | IP54 |
| Applicable Scenario | Hotel Lobby, Office Building Main Entrance |
Two-Wing Revolving Door Product Overview
This series of two-wing revolving doors adopts a central rotating structure design, with a fixed outer ring and a 360° smooth rotating inner fan, effectively isolating indoor and outdoor airflow and reducing air conditioning energy consumption by over 30%. The door frame is made of high-strength aluminum alloy profiles with fluorocarbon spraying, offering excellent weather resistance.
Equipped with infrared anti-pinch sensors, emergency stop buttons, and a backup power system, the inner fan can be manually pushed open for evacuation during power outages. Supports integration with facial recognition and access control systems, meeting the intelligent management needs of high-end commercial buildings.
- Variable frequency drive, smooth start without impact
- Double-layer tempered glass, sound and thermal insulation
- Switchable to sliding mode at night
- 3-year full machine warranty
